Technical Specifications

Head: KM5121-30PL
DROP VOLUME: 30 PL
DRYING SYSTEM: INFRARED, HEATER & FAN
PRINT WIDTH: 3.3 MTR
FRONT & REAR HEATER: 3750 WATT
INFRARED HEATER: 4200 WATT INK SYSTEM: NEGATIVE PRESSURE
BOARDS: BYHX
RIP SOFTWARE: ULTRS/RIN/MAINTOP/PHOTOPRINT MACHINE BOX SIZE: 5400 750 1130 mm(L*W*H)
ELECTRIC POWER REQUIRED: 220V/60A/50HZ
MACHINE MAX POWER: 9095 WATT
PRINTING SYSTEM: 1145WATT
MACHINE BODY SIZE: 4750 940 1400 mm (L*W*H)
GW: 1135 KG
NW: 1035 KG
CONFIGURATION TOUCH SCREEN
